8K 4x2 HDMI Matrix Switch,4 in 2 Out Matrix HDMI2.1 Video Switcher Splitter +Optical & RAC Audio Output,Support 8K 60Hz 4K@120Hz HDR10 ARC with IR Remote Control for PS5 Xbox

Product parameters: HDMI version HDMI 2.1 Input ports HDMI female x4 Output ports HDMI female X2 ,RCA X1, Optical X1 HDMI Video HDMI 2.1,HDCP 2.3,8K 60Hz 4:4:4 8bit 48Gbps HDR Dolby Vision, 4K 60Hz 4:4:4 10bit HDR10,HDR Dolby Vision, 4K 2K,1080p,1080i,3D,1080P 120Hz,24bit,30bit,36bit deep color HDMI Audio Dolby Digital 5.1CH Audio,Dolby Atmos,Dolby TrueHD,DTS-HD Master,LPCM 2.1CH,5.1CH In matrix mode(In this mode, the outputs of A and B are different), output ports A and B cannot output 8K signals at the same time. Only one group is allowed to output 8K and the other group output 4K or less. Suggest HDMI cable length HDMI 2.1 standard cable, 4320P/AWG 26 ≤3m/10 feet, 2160P/AWG 26 ≤5m/16.5 feet, 1080P/AWG 26 ≤10m/33 feet Compatible systems Windows, Mac OS, and Linux. Drive-free. 8K60Hz& 4K120Hz High Resolution: Supports a multitude of video resolutions, including 480P/720P/1080P/2160P @24/25/30/50/60/ 100/120Hz;Up to 4320P@50/60Hz Support HDR10/Dolby Vision Support HDMI 2.1 and HDCP2.3,Support 48Gbps data rate and tmds clock up to 1Ghz Package Contents: 4 x 2 HDMI Matrix X1 Remote Control x1 User Manual x1 Power Adapter

• 【Advanced high-tech high-quality products】: This 4X2 HDMI matrix, it can switch between 4 input signal source devices and distribute the signal to 2 monitors (2 monitors can display the same picture or different pictures), the output port OUTA or OUTB can achieve independent audio output through Optical SPDIF or RCA stereo.
• 【8K60HZ/4K120HZ High Resolution】: Please preferentially connect 8K TV to OUTB. OUTA outputs 8K@60HZ or 4K@120HZ resolution only in split mode (In this mode, OUTA and OUTB select the same input source). The maximum output resolution is 8K@30HZ or 4K@60HZ in other modes.If you want to output 8K @60Hz, 4K @120Hz resolution, please make sure your HDMI source device, cable and monitor can support the resolution and refresh rate you need to output.
• 【HDR10 and Dolby Vision HDRWith power-off memory function 】: HDMI Matrix 4x2 can extract audio signal from HDMI input source and output via optical SPDIF (supports 5.1CH Dolby HD, DTS HD, Dolby Atoms, Dolby AC3, DTS or 2CH LPCM) and analog RCA (supports 2CH LPCM only).the setting status of the selected channel and function will be saved, and the saved data will be automatically recalled for configuration after power-off the next time the machine is turned on.
• 【support ARC or CEC function 】: If you need to use the ARC or CEC function, you must connect the TV to the OUTB port. When using the ARC function, it is required that the HDMI input port of the TV must support and the ARC function has been turned on
• 【 Wide Compatibility】: This audio splitter works with all kinds of HDMI source devices. HDMI Input: DVD, Apple TV, PS3/PS4/PS5, PC/Laptop, etc. HDMI Output: Full HD TV, Monitor, Projector. Audio output: Speakers, amplifiers, sound bars or other sound systems.
