12V 24V 90W DC Gear Reducer Motor Output Shaft 12mm High Speed Adjustable DC Motor CW CCW(12V Output shaft12mm,28rpm,Only Motor)
Product details
| Management number | 211447214 | Release Date | 2026/04/04 | List Price | $152.84 | Model Number | 211447214 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Motors12V 24V 90W DC Gear Reducer Motor Output shaft 12mm High Speed Adjustable DC Motor CW CCWGearbox speed ratio:3K,5K,7.5K,10K,12.5K,15K,18K,20K,25K,30K,36K,40K,50K,60K,75K,100K,120K,150K,180K,200KNo-load speed of the motor2100rpm, load speed of the motor1800rpm.No load output speed:speed ratio 3K(700rpm),speed ratio5K(420rpm), speedratio7.5K(280rpm), speed ratio 10K(210rpm), speed ratio12.5K(168rpm), speedratio 15K(140rpm), speed ratio 18K(117rpm), speed ratio20K(105rpm), speedratio 25K(84rpm), speed ratio 30K(70rpm),speed ratio36K(58rpm),speed ratio40K(52.5rpm),speed ratio50K(42rpm),speed ratio60K(35rpm),speedratio75K(28rpm),speed ratio100K(21rpm),speed ratio120K(17.5rpm),speedratio150K(14rpm),speed ratio180K(12rpm),speed ratio200K(10.5rpm)XD-5D90GN Motor *1pc or XD-5D90GN Motor *1pc and bracket*1pc : 12V3.4kg.cm/24V3.6kg.cmModel Number : XD-5D90GNContinuous Current(A) : 12V 12A/24V 5.5AConstruction : Permanent MagnetType : Gear MotorProtect Feature : Totally EnclosedCommutation : BrushEfficiency : IE 2Certification : Output Voltage : 90WReducer output shaft diameter : 12mmOutput speed : 100-600rpmVoltage : 12V/24V
- Motors
- 12V 24V 90W DC Gear Reducer Motor Output shaft 12mm High Speed Adjustable DC Motor CW CCW
| Model | HIVJEEDYH |
|---|---|
| Brand Name | HIVJEEDYH |
| Model Name | HIVJEEDYH |
| Manufacturer | HIVJEEDYH |
